Electric tapping arm M3–M16 with touchscreen PLC control

The HU AT DS16 M3-M16 is a professional electric tapping arm designed for fast, precise, and ergonomic threading of M3 to M16 threads. Thanks to its powerful servo motor and advanced PLC control via touchscreen, this tapping arm operates with exceptional accuracy and low noise levels. Speed, rotation direction, and tapping parameters are easily adjusted via the user-friendly touchscreen, ensuring consistent quality and high productivity.

The flexible arm design allows the tapping head to be easily positioned in various angles and positions. This makes the machine suitable for both batch production and single-piece manufacturing in a wide range of industrial environments.

Advantages:
Powerful servo motor
Significantly quieter than a pneumatic tapping arm
Intelligent PLC control for optimal process management
Flexibly positionable tapping head for different workpieces
Variable adjustable speed
Fast positioning above the workpiece
Consistent thread quality and reduced risk of tap breakage
Suitable for both small batches and production environments

Applications:
Thread tapping in stainless steel, steel, aluminium, and other non-ferrous materials
Inserting of inserts and threaded bushings
Production and assembly work
Serial thread machining
Maintenance and repair work

Target audience:
Metalworking companies
Welding companies
Sheet metal fabrication companies
Machine builders
Technical services and maintenance departments
General industry

Supplied with 9 tap holders:
M3 – 3.5*2.7 (DIN 371 / type 19 size 1)
M4 – 4.5*3.4 (DIN 371 / type 19 size 1)
M5 – 6*4.9 (DIN 371 / type 19 size 1)
M6 – 6*4.9 (DIN 371 / type 19 size 1)
M8 – 8*6.2 (DIN 371 / type 19 size 1)
M10 – 10*8 (DIN 371 / type 19 size 1)
M12 – 9*7 (DIN 376 / type 19 size 1)
M14 – 11*9.0 (DIN 376 / type 19 size 1)
M16 – 12*19 (DIN 376 / type 19 size 1)
